Description:
To eliminate the need for building costly upstands when mounting roof units, Fantech has developed the Profile Fan. Mounting these units is as easy as cutting a rectangular hole in the roof, placing the fan in position, and fixing it with tek-screws or similar. No flashing is required. All that is needed to weatherproof the Profile Fan is a bead of silicon. The Profile Fan is available with either axial or centrifugal impellers and has profiles to suit Trimdek*, Custom Orb*, KlipLok*, Spandek* and Brownbuilt styles. A Relief Air Vent, model PFR30 is also available.
Construction:
Cowl, base and inlet spigot are of UV-stabilised plastic. Steel components have a corrosion-resistant finish.
Motors:
• Type - external rotor, squirrel cage induction motor.
• Electricity supply - 220V-240V, single-phase, 50Hz.
• Bearings - sealed-for-life, ball.
• Speed-controllable.
Internal Thermal Protection:
Auto-reset thermal contacts are fitted as standard.
Testing:
Air flow tests to BS848:Part 1, 1980. Noise data is based on tests conducted in accordance with BS848:Part 2, 1985.
Special Features:
Suitable for free and ducted intake installations. For ducted installations, an inlet spigot is available as an optional extra. Can be mounted at angles of 30°.
Suggested Specification:
• The roof ventilators shall be of the Profile Fan Series as designed and manufactured by Fantech Pty. Ltd.
• The axial or centrifugal impellers shall be direct driven by speed controllable external rotor motors with integral thermal contacts.
• Plastic components shall be UV-stabilised. Steel components shall have a corrosion-resistant finish.
• All models shall be fully tested to BS848:Part 1, 1980 for air flow.
• Noise data is based on tests conducted to BS848, Part 2, 1985.
