Haneco Lighting | Haneco | Haneco Downlights

Haneco Lighting

Matrix LED Panel Light (600x600) 36w 4k/5k Haneco Lighting - 2000343, 2000344

$73.49

Description:

Matrix is a high performance LED panel that delivers impressive efficacy and low glare rating with superior heat dissipation.

Specification:

Input Power: 36w
Lumen Output: 3880lm or 3810lm
Install: Metric T-Bar Celing Grid
Dimming Options: Non-Dimmable
Trim Colour: White
IP Rating: IP40
Efficacy: 108lm/W or 106lm/W
LED: SMD
Colour Temperature: 4000k or 5000k
CRI: >80
Beam Angle: 110°
Supply Input: 220-240V, 50/60Hz
Useful life @Ta25° (L70): 50,000hr
Housing: Powder Coated Steel
Optics: Polycarbonate Diffuser
Total Weight: 1.85kg
Warranty: 5yr

Dimension:

Length: 600mm
Width: 600mm
Height: 33mm

Order Code:

2000343 - 4000k
2000344 - 5000k

90mm LED Downlight Kit White 2000260 Haneco

$11.54

Description:

Retrofit recessed downlight kit with gimbal feature, white finish & aluminium frame. This is great to match your traditional MR16 or GU10 halogen recessed downlights.

You have 3 purchase options:

Frame only

Frame + MR16 Tails

Frame with GU10 tails

Specifications:

Finish: White
Material: Aluminium frame
Face Diameter: 100mm
Cutout Diameter: 90mm
Frame Shape: Round
Frame Type: Adjustable Gimbal

Order Code:

2000260 - Round White (HHG108A)

LED Dimming Switch 350w in White Haneco Lighting - 2001203

$75.59

LED Dimming Switch is designed to ensure trouble free LED dimming with LED lights.

Features:

Trailing edge LED dimming switch suitable for compatible LED fittings
Maximum load 350w (e.g. over thirty 10w LED downlights)
Compatible with standard wall plates and apertures
Easy adjustment of minimum LED dimming or maximum LED dimming
2-way and 3-way compatible
Integrated switch and LED dimmer knob
Easy to locate in the dark with subtle LED backlighting that can be turned off
Simple 2 wire design for easy installation

Applications:

Residential, hospitality, commercial

Order Code		Dimming Method	Max Load Wattage
2001203		Phase-Cut Dimming	350w

7w Fluorescent 2 Foot Globe Daylight 6500k 2001135

$27.29

Description:

The LED Tube supersedes old fluorescent tubes and not only delivers better energy efficiency, but also has a safer, more enduring and virtually unbreakable non toxic tube.

Features:

LED TUBE Provides over 50% energy savings when replacing conventional fluorescent
Virtually unbreakable polycarbonate body with no mercury or glass
Wide illumination with 200 degree beam angle
5 year warranty

Specification:

IP Rating: IP20
Beam Angle: 200°
CRI: >80
Non-Dimmable
Expected Lifetime: 50,000hr

Applications:

Supermarkets, factories, residential, replacement

Order Code	Size	CCT	Watt	Lumen	lm/W	Rebatable
2001135	600mm	6500k	7w	850lm	121 lm/W	VEET

Rugged Outdoor LED Batten Light CCT 20w/40w/60w Haneco Lighting

$114.44

Description:

Outdoor LED battens with a robust IK08 vandal resistant grade. They have a HACCP food grade rating. Models are available with smart technology Intellisensor and Ecoswitch to minimise waste. Emergency models are rated IP54.

Features:

Outdoor LED batten with weather resistant UV stabilised polycarbonate body and diffuser
Tritone colour temperature selection
Stainless steel tamper proof clips for public spaces
Dual intensity selection with Ecoswitch on some models
Intellisensor occupancy sensor available on some models
Three hour self charging back-up Emergency battery (Ni-Cd) on some models
PG16 cable entry with optional knockout
IK08 vandal resistant
Some models are approved for VEET, REES & IPART
1 & 2m suspension kits available
5 year warranty (1 year warranty on battery in emergency models)

Specification:

Impact Rating: IK08
Beam Angle: 120°
CRI: >80
Non-Dimmable
Expected Lifetime: 50,000hr

Applications:
Outdoor, industrial, sports halls, public amenities

Code	Size	Feature	CCT	Watt	Lumen	lm/W
2001164	600mm	Tritone	4000k 5000k 6500k	20w 20w 20w	1850lm 1990lm 1850lm	93lm/W 100lm/W 93lm/W
2001165	600mm	Tritone, Emergency	4000k 5000k 6500k	20w 20w 20w	1850lm 1990lm 1850lm	93lm/W 100lm/W 93lm/W
2001168	1200mm	Tritone – Ecoswitch REES, VEET, IPART	4000k 5000k 6500k	20w-40w 20w-40w 20w-40w	2230lm-4090lm 2250lm-4410lm 1970lm-4050lm	111-102lm/W 113-110lm/W 98-101lm/W
2001066	1200mm	Tritone – Ecoswitch REES, VEET, IPART Emergency	4000k 5000k 6500k	20w-40w 20w-40w 20w-40w	2230lm-4090lm 2250lm-4410lm 1970lm-4050lm	111-102lm/W 113-110lm/W 98-101lm/W
2001068	1200mm	Tritone, Intellisensor, Emergency	4000k 5000k 6500k	40w 40w 40w	4085lm 4411lm 4049lm	102lm/W 110lm/W 101lm/W
2001170	1500mm	Tritone	4000k 5000k 6500k	60w 60w 60w	5600lm 6000lm 5700lm	93lm/W 100lm/W 95lm/W

Matrix G3 LED Panel Light (600x600) Power Switchable 25-36w CCT in White

$81.68

A Tritone, evenly lit LED panel with Flicker Free power switchable driver.

MATRIX G3 is a high performance Tritone LED panel that delivers impressive efficacy and low glare rating with superior heat dissipation. It comes with a flicker free driver.

Specification:

Housing: Steel
Optics: Polycarbonate Diffuser
Colour: White
Wattage: 25/28/32/36w
Lumen: 3000lm / 3300lm / 3700lm / 4100lm
Colour Temperature: CCT (4000k / 4500k / 5000k)
CRI: >80
Beam Angle: 110°
Dimmable: No
Voltage: 220-240v, 50/60Hz
IP Rating: IP40
Warranty: 5 Year

Dimension:

Length: 595mm
Width: 595mm
Height: 35mm
Weight: 1.9kg

Matrix G3 LED Panel Light (1200x300) Power Switchable 25-36w CCT in White

$81.90

A Tritone, evenly lit LED panel with Flicker Free power switchable driver.

MATRIX G3 is a high performance Tritone LED panel that delivers impressive efficacy and low glare rating with superior heat dissipation. It comes with a flicker free driver.

Specifications:

Colour: White
Wattage: 25/28/32/36w
Lumens: 3000 / 3300 / 3700 / 4100 lm
Install: Metric T-Bar Ceiling Grid
Dimming Options: Non-Dimmable
CCT: 4000 / 4500 / 5000K
CRI: >80
Beam Angle: 110°
IP Rating: IP40
IK Rating: N/A
IC Rating: IC
Efficacy: 110 lm/W
LED: SMD
Driver: Remote
Supply Input: 220-240v, 50/60Hz
Driver Output: Voltage 36V DC
Power Factor: >0.9
LED Input Current (nominal): 700/800/900/1000mA
Useful life @Ta25° (L70): 50,000hr
Housing: Steel
Optics: Polycarbonate Diffuser
Adjustable Angle: N/A
Fixings/Hardware: N/A
Connection Type: 1.2m Flex & Plug
Operating Ambient Temp.: -20 to 45°C
Electrical Classification: Class 2
Warranty: 5yr

Dimensions:

Length: 1195mm
Width: 295mm
Height: 35mm
Weight: 1.9kg

Matrix Recessed Mount Frame: To Suit Matrix LED Panel Light 1200 x 300 ONLY - 2002118

$62.99

Matrix Plaster Recess One-Piece Frame for compatible Haneco Matrix series 1200mm x 300mm LED Panels.

ONLY guaranteed compatibility with Haneco LED Panel lights listed below, we cannot guarantee across other models and brands.

Specifications:

Haneco Matrix Panels Compatible: 2000341, 2000342
Colour: Powdercoated White
Material: Aluminium
Fixings: Included
Product Code: 2002118

Dimensions:

Length: 1230mm
Width: 330mm
Depth: 41mm

Accessories - Suspension Kit to suit Haneco Matrix LED Panel Lights - 2001880

$28.34

Specifications:

Suits: Haneco MATRIX LED Panel Lights
Material: Stainless Steel
Suspension length: 0.6 to 2.0m adjustable
Suspension Type: Y-Type suspension cable
Please view installation instructions on the PDF "Download Tech Spec" above.
Matrix Panels Compatible: 2000341, 2000342, 2000343, 2000344

TRIPROOF-YG Outdoor LED Batten Light 1200mm 20/40w Yellow/Green

$169.04

TRIPROOF YG are weatherproof LED battens with a striking robust design and suitability for higher ambient temperatures. This model offers a specific Yellow colour output suitable for attracting fewer insects than traditional white lights, and a specific Green colour output suitable for eyewash bays.

Applications:

Kitchen / Food Prep, Awnings, Side of Building, Hangers, Manufacturing Facilities, General Industrial, Medical Facilities.

Specifications:

Colour: Grey
Material: Polycarbonate
Globe Type: LED
Wattage: 20/40w
Colour Temperature: Yellow (580 nm) & Green (528 nm)
Lumens: 20w - G: 2556 / Y: 2564 lm | 40w - G: 4431 / Y: 4634 lm
IP Rating: IP65
IK Rating: IK08
Voltage: 220-240v AC, 50/60Hz
Dimmable: No
CRI: >80
Beam Angle: 120°
Warranty: 5 Years

Dimensions:

Length: 1215mm
Width: 116mm
Height: 74mm

Uno Linear LED Batten Light CCT 1200mm 40w in Black or White

$206.84

UNO is a stylish and minimalistic aluminium profile luminaire, offering outstanding performance and design flexibility for architecturally demanding applications.

UNO is a linear LED batten with selectable color temperature with surface and suspension mount kits included.

Applications:

Hallways, Entrance, Accent / Display / Feature Lighting, Showrooms, Boardroom / Meeting Rooms, Function Areas, Food Courts, Retail Spaces, Hotel Common Areas, Restaurants / Cafes, Cocktail Lounge, Kitchen / Food Prep.

Specifications:

Colour: Black, White
Material: Aluminium, Polycarbonate Diffuser
Globe Type: LED
Wattage: 40w
Colour Temperature: CCT (3000k / 4000k / 5000k)
Lumens: 3400lm / 3500lm / 3400lm
Dimmable: Yes
Voltage: 220-240v, 50/60Hz
IP Rating: IP20
CRI: >80
Beam Angle: 110°
Warranty: 5 Years

Dimensions:

Length: 1204mm
Width: 69mm
Height: 87mm

Matrix G3 LED Panel Light (600x1200mm) 48w CCT in White

$154.35

A 48w Tritone, evenly lit LED panel with Flicker Free driver.

MATRIX G3 is a high performance Tritone LED panel that delivers impressive efficacy and low glare rating with superior heat dissipation. It comes with a flicker free driver.

Specifications:

Colour: White
Material: Steel, Polycarbonate Diffuser
Wattage: 48w
Voltage: 220-240v, 50/60Hz
Colour Temperature: CCT - 4000 / 4500 / 5000k
Lumens: 5430 / 5500 / 5680lm
IP Rating: IP40
Dimmable: No
CRI: >80
Beam Angle: 110°
Warranty: 5 Years

Dimension:

Length: 1195mm
Width: 595mm
Height: 33mm
Weight: 3.9kg
