Heatstrip THX Series Max Accessories Thermofilm - ZBRAK-132S, THXAC

$46.77

Description:
The installation of HEATSTRIP® Max is simple and easy with the standard mounting brackets supplied. For other more challenging locations there are a range of mounting options available.

The HEATSTRIP® Max can be mounted directly to the ceiling, angled downwards on a wall, suspended on chains or poles; attached to beams or poles; or 2 units together. Refer to the following pages for more detailed information on each mounting option.

Order Code	Description	Dimensions (mm)	Weight (kg)	Material
ZBRAK-132S	Replacement standard THX brackets (2 in pack)	-	-	-
THXAC-018	Twin mounting bracket kit (2 in pack)	220 x 100 x 25	1	316 SS
THXAC-019	End to End brackets - used to join 2x THX heaters	260 x 50 x 50	0.5	316 SS
THXAC-020	Extension Mounting Pole - 300mm	-	-	-
THXAC-021	Extension Mounting Pole - 600mm	-	-	-
THXAC-022	Extension Mounting Pole - 900mm	-	-	-
THXAC-023	Extension Mounting Pole - 1200mm	-	-	-
THXAC-030	Flush Mount Enclosure THX2400	-	-	-
THXAC-031	Flush Mount Enclosure THX3600	-	-	-

Heatstrip THH-A Series Classic Mounting Accessories Thermofilm - THHAC

$53.32

Decription:

Installing the HEATSTRIP® Classic is simple and easy using the standard mounting brackets supplied. For other irregular locations there are range of mounting options available - refer to diagrams below.

The HEATSTRIP® Classic can be mounted directly to the ceiling, angled downwards on a wall, fitted flush with the ceiling, suspended on chains or poles, attached to beams or poles, mounted end-to-end, or 2 units side-by-side together. Refer to the following pages for more detailed information on each mounting option.

Order Code	Description	Hole Cutout Dimensions (mm)	Overall Dimensions (mm)	Packaged Dimensions (mm)	Materials	Weight (kg)	Notes
THHAC-001	Pole/beam mounting brackets (2 in pack)	-	-	150 x 150 x 50	316 SS	0.5	-
THHAC-003	Suspension/chain mounting bracket THH2400A, THH3200A	-	-	1200 x 120 x 50	316 SS	2	-
THHAC-004	Extension mounting brackets (2 in pack, brackets only), anodised silver	-	-	150 x 150 x 50	316 SS	1	Brackets only (for use with 25x25x1mm tube)
THHAC-005	Extension Mount Pole 300mm (2 in pack with brackets), anodised silver	-	-	300 x 150 x 50	316 SS	2	Kit includes 2x300mm extension pole, screws and brackets
THHAC-006	Extension Mount Pole 600mm (2 in pack with brackets), anodised silver	-	-	600 x 150 x 50	316 SS	2	Kit includes 2x600mm extension pole, screws and brackets
THHAC-007	Extension Mount Pole 900mm (2 in pack with brackets), anodised silver	-	-	900 x 150 x 50	316 SS	2.5	Kit includes 2x900mm extension pole, screws and brackets
THHAC-008	Extension Mount Pole 1200mm (2 in pack with brackets), anodised silver	-	-	1200 x 150 x 50	316 SS	3	Kit includes 2x1200mm extension pole, screws
THHAC-010	Flush mount enclosure THH1800A	1160 x 230	1210 x 280 x 125	-	-	6	-
THHAC-011	Flush mount enclosure THH2400A	1420 x 230	1470 x 280 x 125	-	-	8	-
THHAC-012	Flush mount enclosure THH3200A	1830 x 230	1880 x 280 x 125	-	-	9	-
THHAC-016	Twin mounting bracket kit (2 in pack)	-	-	300 x 50 x 50	316 SS	0.25	-
THHAC-017	End to end bracket (to join 2 x THH-A heaters)	-	-	300 x 150 x 50	316 SS	0.5	-
ZBRAK-113S	Replacement Standard Bracket for all THH-A models	-	-	-	-	-	-

Heatstrip (THH-A) Classic Radiant Electric Heaters 1800w, 2400w, 3200w Black

$567.87

Premium quality, stylish & slimline electric radiant heaters perfect for protected outdoor and indoor applications. Make it a feature in your outdoor area.

Features:

Electric radiant heater ideal for your protected alfresco area, pergola, veranda, café or difficult to heat indoor areas
Stylish, sleek, unobtrusive design with a black front profile
Efficient, cost-effective heating providing gentle warmth
Corrosion protected for even the toughest environment
Easy DIY installation for 2 models (THH1800A & THH2400A. THH3200A must be installed by a licensed electrician) and multiple mounting options
2-year residential warranty and 1-year commercial warranty
Australian designed and engineered

Mounting:

The installation of HEATSTRIP^® Classic is simple and easy with the standard mounting brackets supplied. For other locations, there are a range of mounting options available – (refer to below diagrams). The HEATSTRIP^® Classic can be mounted directly to the ceiling; angled downwards on a wall; fitted flush with the ceiling; suspended on chains or poles; attached to beams/poles/umbrella’s; mounted end-to-end, or 2 units together.

Minimum mounting height (including flush mount) 2.1m^†
Ideal mounting height (including flush mount) 2.2m – 2.5m / 2.1 -2.2m^†
Maximum mounting height (including flush mount) 2.7m / 2.3m^†

The mounting height of the electric heater can have a significant impact on performance. For mounting heights higher than the ideal range, we recommend the use of wires/chains or optional extension poles to reduce the height and ensure the heater is within the ideal range. Heater performance may be affected if outside this range.

Model	Running Cost*	Power (watts)	Current (amps)	Length	Width	Height	Weight (kg)	Lead Length (mm)	Plug	Heating Area (m²)
THH1800A	45c /hr	1800	7.5	1104mm	165mm	48mm	6	1000	Yes	3-4
THH2400A	60c / hr	2400	10	1364mm	165mm	48mm	7	1000	Yes	4-5
THH3200A	80c / hr	3200	13.3	1774mm	165mm	48mm	9	1000	No	5-6

Heatstrip THX Series Max Electric infrared Heaters in 2400w/3600w Thermofilm - THX2400, THX2600

$755.92

Description:

Heatstrip Max is an Australian designed and engineered range of high intensity electric, infra-red radiant heaters ideal for tough outdoor and indoor heating applications.

It has been specifically designed where all others heaters have failed - a high temperature radiant heater with a unique low-glow, shatter proof heating element, perfect even for fully exposed locations.

Applications include outdoor alfresco areas, balconies, pergolas, patios,
verandas, courtyards, garages, sheds, warehouses, showrooms, halls etc

Features:

High temperature electric radiant heater ideal for higher ceilings or more exposed locations
Unique “low glow” incoloy element – no more blinding light
Significant running cost savings compared to bottled gas heaters
Commercial grade quality and construction – 2 year warranty
Corrosion resistance provided by the anodized alloy casing
2 models – DIY (THX 2400) or hard wired (THX 3600).

Order Code	Wattage	Amps	Dimension (LxWxH) mm	Weight	Lead Length	Plug	Running Cost	Others
THX2400	2400w	10	854x170x80	6kg	1000mm	Yes	48c / hr	Supplied with lead and plug - DIY
THX3600	3600w	15	1184x170x80	8kg	1000mm	No	72c / hr	Must be hard wired

Heatstrip THE Series Elegance Mounting Accessories Thermofilm - ZBRAK-113W, THEAC

$46.77

Description:

Standard Mounting Brackets. The HEATSTRIP Elegance comes with a pair of standard mounting brackets. These adjustable brackets allow direct ceiling, wall or pole/beam mounting, and come with preset angle options of parallel, 22.5° and 45°.

The Flush Mount Enclosure is an ideal way to neatly install the HEATSTRIP into a ceiling. They are available for all HEATSTRIP Elegance models, and are supplied as a one-piece unit suitable for mounting individusal heaters. Flush
mounting can be used with plaster or timber lined ceiling materials.

An ideal mounting height is 2.3m-2.5m, with a maximum ceiling height of 2.7m in an outdoor enclosed environment.
Maximum mounting heights should be strictly followed, otherwise the performance of the units may be reduced.

A minimum clearance of 50mm behind the enclosure must be provided.

The enclosure is manufactured from powder coated steel.

The Extension Mount Pole allows HEATSTRIP Elegance units to be lowered from high ceilings using rigid connections. The standard length options as part of the kit are 300mm, 600mm, 900mm and 1200mm.

The kits include all brackets, poles and screws necessary for connection to the heaters, however it does not include
screws for attachment to the ceiling.

Order Code	Description	Hole Cutout Dimensions (mm)	Dimensions (mm)	Weight (kg)
ZBRAK-113W	Replacement standard bracket for all THE model	-	115 x 20 x 100	0.2
THEAC-040	Flush mount enclosure - THE1800	1030 x 240	1080 x 290 x 125	6
THEAC-041	Flush mount enclosure - THE2400	1260 x 240	1310 x 290 x 125	8
THEAC-042	Flush mount enclosure - THE3600	1860 x 240	1910 x 290 x 125	9
THEAC-043	Extension Mount Pole Kit - 300mm (2 in pack), off-white	-	-	0.21
THEAC-044	Extension Mount Pole Kit - 600mm (2 in pack), off-white	-	-	0.38
THEAC-045	Extension Mount Pole Kit - 900mm (2 in pack), off-white	-	-	0.55
THEAC-046	Extension Mount Pole Kit - 1200mm (2 in pack), off-white	-	-	0.71

Heatstrip Elegance Radiant Electric Outdoor Heaters 1800w/2400w/3600w Thermofilm - THE Series

$669.85

Description:

Heatstrip Elegance is a range of stylish, premium, high-intensity electric panel heaters. With huge running cost savings compared to bottled gas heaters, The Heatstrip Elegance by Thermofilm is ideal for outdoor undercover protected applications, both residential and commercial. These include protective alfresco dining and BBQ areas, patios, verandahs, courtyards, and balconies.

Benefits:

Radiant heaters are often the most effective and preferred way to heat an outdoor or tough-to-heat indoor area. Unlike traditional convection heaters, Our HEATSTRIP® range heaters will heat directly heat the surface of the objects through infra-red waves, while convection heaters heat the air between objects.

Heatstrip Elegance electric radiant heaters are more effective within an outdoor or uninsulated indoor area because they provide targeted warmth directly to the people and objects in their path.

Using the radiant heating principle, HEATSTRIP® can provide comfortable heating for undercover outdoor and indoor open areas. Our innovative design of the HEATSTRIP® enables comfortable and even heat dispersion from the heater surface with minimal operational cost.

Features:

Electric radiant heater perfect for your protected alfresco area, pergola, verandah or cafe
The elegant, slimline design and “off-white” colour blends in seamlessly with most white ceilings
World leading element design produces a more compact and higher output heater
Significantly more cost-effective than bottled gas heaters
Corrosion-resistant to handle the toughest outdoor environments
Convenient DIY installation of Heatstrip1800W, Heatstrip 2400W, and Heatsrip 3600W models and hardware.
Comes with adjustable standard bracket
Other optional mounting brackets and controllers
2 year residential and 1-year commercial warranty

Model	Running Cost*	Power (watts)	Current (amps)	Dimension (mm)	Weight (kg)	Lead Length (mm)	Plug	Heating Area (m²)
THE1800	45c / hr	1800	7.5	974 x 170 x 48.5	4	1000	Yes	3-4
THE2400	60c / hr	2400	10	1204 x 170 x 48.5	7	1000	Yes	4-5
THE3600	90c / hr	3600	15	1804 x 170 x 48.5	9	1000	No	5-6

Heatstrip THY Series intense Mounting Accessories Thermofilm - ZBRAK-132X, THYAC

$46.77

Description:

The Extension Mount bracket allows HEATSTRIP® Intense units to be lowered from high ceilings using rigid connections. The standard length options as part of the kit are 300mm, 600mm, 900mm and 1200mm.

The extension mount bracket utilises components from the standard bracket kit which is supplied with each heater.

Order Code	Description	Colour	Packaged Dimensions (mm)	Weight (kg)	Materials
ZBRAK-132B	Replacement standard THY brackets (2 in pack)	Black	125 x 100 x 40	0.2	Alloy
ZBRAK-132W	Replacement standard THY brackets (2 in pack) White	White	125 x 100 x 40	0.2	Alloy
THYAC - 047	Kit includes 2x 300mm extension pole	Black	300 x 150 x 50	0.21	Aluminium
THYAC - 048	Kit includes 2x 600mm extension pole	Black	600 x 150 x 50	0.38	Aluminium
THYAC - 049	Kit includes 2x 900mm extension pole	Black	900 x 150 x 50	0.55	Aluminium
THYAC - 050	Kit includes 2x 1200mm extension pole	Black	1200 x 150 x 50	0.71	Aluminium
THYAC - 051	Flush mount enclosure - THY2200	Black	1150 x 204 x 190	5kg	Steel
THYAC - 052	Flush mount enclosure - THY3200	Black	1410 x 204 x 190	7kg	Steel
THYAC-053	Flush Mount Enclosure - THY2200W	White	1150 x 204 x 190	5kg	Steel
THYAC-054	Flush Mount Enclosure - THY3200W	White	1410 x 204 x 190	7kg	Steel

Heatstrip Hard Wire Controller w/ Timer and Heat Settings and Remote Thermofilm - TT-MTM2

$198.80

Description:
The TT-MTM2 wall mounted controller is suitable for the Classic (THHA), Elegance (THE), Intense (THY& THYW) and the Max (THX) range. This controller allows for Heat modulation of High/Medium and low controls, timer and on/off functionality.
It is possible to use one controller to control multiple heaters. However the maximum current rating of 16A must not be exceeded. For example, 2 x THH1800A (Classic Heater) can be connected to the controller. This controller needs to be installed by a licenced electrician.

Features:

Simple on/off function with LED indicators
3 heat settings (High/Medium/Low)
Automatic timer - 1 / 2 / 4 hour options
Remote control included (operational distance is approximate 8m in a straight line)
Suitable for operation of single or multiple heaters
Must be hard wired
Max. 16 amps
• Wall Mounted

Compatible Heatstrip Heater Range:

Heatstrip Classic (THHA)
Heatstrip Elegance (THE)
Heatstrip Intense (THY & THYW)
Heatstrip Max (THX)

Product Code:
TT-MTM2

Heatstrip Plug-in Controller DIY Timer w/ Remote Thermofilm - TT-MTR-PLUG

$89.81

We would recommend the use of a controller to:

• Provide improved flexibility for your heating system
• Maximise heating levels for your comfort
• Ensure optimum performance
• Reduce operating costs

Features:
• Plug-in DIY timer switch
• On/off function with LED indicators
• Automatic timer - 1 / 2 / 4 hour options
• Remote control included
• Ideal for HEATSTRIP® heaters and most plug-in appliances
• Max. 10 amps

Typical Applications:
• Indoor heating in a well insulated, enclosed area (office, classroom etc)

Order Code:
TT-MTR-PLUG

Heatstrip THY Series intense infrared Electric Outdoor Heater 2200w/3200w Thermofilm - THY2200, THY3200

$464.80

Description:

The new HEATSTRIP intense Wall / Ceiling mounted electric infra-red heater is a modern and attractive outdoor heating solution. The high temperature output of the HEATSTRIP Intense is perfect for exposed outdoor sites, high ceilings and hard to heat indoor and outdoor applications. With black and off-white models available, these heaters can blend into a white ceiling, or be a feature to any outdoor area.

Features:

Ideal for undercover protected and semi-exposed outdoor locations
Easy DIY installation for 2200W unit, 3200W heater must be installed by a licensed electrician
High quality construction with a new hexagonal grille
Carbon filament infra-red heating element provides high performance instant heat
2-year residential and 1-year commercial warranty

Specification:

Material: Alloy
Colour: Black
Indoor Use: Yes
Outdoor Use: Yes
Corded: Yes
Cordless: No
Voltage (volts): 240v
Cord Length (cm): 1000

Order Code	Wattage	Width	Height	Length	Weight
THY2200	2200w	120mm	90mm	1068mm	6kg
THY3200	3200w	120mm	90mm	1270mm	7kg

Heatstrip Gas Heater Ceiling Mounting Pole Kit 500mm Thermofilm - TGHAC-004

$193.65

Description:

The ceiling mounting pole is an ideal way of mounting the TGH34WN-2 where wall mounting is not capable.

Features:

Allows heater to be suspended from a ceiling
Perfect for area's where wall mounting is not capable
Conceals gas line for elegant clean look

Specification:

Material: Mild Steel
Colour: Black
Weight: 4kg

Dimension:

Product Dimensions (mm): W:70 H:130 L:505
Package Dimensions (mm): W:165 H:155 L:650

Heat Shield for Wall Mounted Gas Heater 300mm Thermofilm - TGHAC-003

$142.19

Description:

Extended Wall Mounting Heat Shield. Allows for low clearance installations - 300mm from HeatShield to ceiling.

Heatstrip THS-A Series Indoor Electric Radiant Strip Heaters Mounting Accessories Thermofilm - THSAC

$48.64

Description:

The HEATSTRIP® Indoor can be mounted directly to the ceiling; angled downwards on a wall; fitted flush with the ceiling; suspended on chains or mounted end-to-end.

PLEASE NOTE: These are the Mounting Accessories for the THS-A heater. This does NOT include the heating unit itself.

Order Code:

ZBRAK-92 - Standard Mounting Bracket - Sold as a pair
THSAC-020 - Angle Mounting Bracket - Sold as a pair
THSAC-024 - T Bar Mount Frame (THS 1200A)
THSAC-025 - Flush mount enclosure THS 800A
THSAC-026 - Flush Mount Enclosure (THS 1200A)
THSAC-027 - Flush Mount Enclosure (THS 1800A)
THSAC-028 - Flush Mount Enclosure (THS 2400A)

Heatstrip Wall Mounted Natural Gas Heater (NG) Thermofilm - TGH34WN-2

$644.00

Description:

HEATSTRIP® Wall Mounted Natural Gas (NG) heater is a stylish addition to any outdoor area, where mains Natural Gas is preferred. World Class design aesthetics, heat output and performance, for both residential and commercial applications.

So many uses:
Residential

Al-fresco & outding dining areas
Patios & outdoor kitchens
Courtyards, balconies, verandas

Hospitality & Commercial

Outdoor cafes & restaurants
Outdoor Pubs, Clubs, beer gardens, smoking and gaming areas

Features:

34MJ, 4 tile commercial quality ceramic burner, for connection to mains Natural Gas (NG)
Electronic battery ignition with micro-switch On/Off operation and stainless steel pull cords. Electrical connection not required
Protective grille and reflector included as standard, to guarantee safe operation. Reflector design ensures that only a minimum of 500mm overhead clearance is required (add TGHSHIELD for 300mm clearance)
Wall mounting bracket allows for multiple mounting angles, and is extremely robust to provide strength and support
2 year residential and 1 year commercial warranty

Specification:

Tiles: 4 Ceramic Tiles
Gas Consumption: 34 MJ/Hr
Ignition: Electronic Battery (AA battery)
Hose Connection: 5/8”-18UNF (3/8”SAE) (Includes 300mm hose and NG regulator)
Gas Pressure: 1.00 KPA
Injector Size: 1.40mm*4
Weight(kgs): 11.5
HEATING AREA(m²): 16 sqm² (4m x 4m)
Materials of Construction: E-coated mild steel with powder coat finish. Grille & reflector with extra high temperature protection.

Dimension:

Width: 650mm
Depth: 190mm
Height: 380mm

Heatstrip THS-A Series Indoor Electric Radiant Strip Heaters in 800w/1200w/1800w/2400w/ Thermofilm - THS

$320.88

Description:

Modern slimline solution for energy efficient, low cost indoor heating. Using the radiant heat principal, HEATSTRIP® can provide an effective and efficient,
yet stylish heating solution for demanding indoor applications.

Specifications:
Voltage: 240v
Hertz: 50Hz
IP Rating: IP45
Colour: Off-white

Wired controllers with timers & remotes SOLD SEPARATELY (TT-MTM, TT-MTR-PLUG)

90 standard mounting bracket included. All other brackets sold separately.
Mounting: Angle Mounting Bracket, Standard Bracket, T Bar Mount Kit, Flush Mount Enclosure, Suspension Mount Bracket, Wall Mounting Bracket (sold separately)

Order Code	Wattage	Amps	Dimension (LxWxH)	Weight	Lead Length	Plug	Running Cost
THS 800A	800w	3.3A	624x235x48	4kg	1000mm	Yes	0.16chr
THS 1200A	1200w	5.0A	924x235x48	6kg	1000mm	Yes	0.24chr
THS 1800A	1800w	7.5A	1384x235x48	8kg	1000mm	Yes	0.36chr
THS 2400A	2400w	10A	1834x235x48	11kg	1000mm	Yes	0.48chr

Conversion Kit for 18kg/45kg Gas Bottle (TGH34PL-2) Thermofilm - TGHAC-001, TGHAC-002

$91.68

Description:
Portable LPG Gas Bottle Conversion Kit.

Order Code	Bottle Size	Kit Inclusions
TGHAC-001	18kg gas bottle Conversion Kit	Custom rear top panel & chain
TGHAC-002	45kg gas bottle Conversion Kit	Custom rear top panel, post back panel & chain

Heatstrip Outdoor Portable LPG Gas Heater 34MJ 4 Tile Thermofilm - TGH34PL-2

$833.00

Description:

The new portable LPG heater incorporates world leading design, quality, heat performance and efficiency to provide a stylish, robust and elegant solution for your outdoor area, alfresco, balcony, patio etc..

New Burner and Hexagonal grille design provide 20% higher radiant output. 15% more slim-line design and Improved wind resistance.

Electronic finger pull ignition for easy On/Off operation. (AA Battery)

So many uses:
Residential

Al-fresco & outdoor dining areas
Patios & outdoor kitchens
Courtyards, balconies, verandas

Hospitality & Commercial

Outdoor cafes & restaurants
Outdoor Pubs, Clubs, beer gardens, smoking and gaming areas

Features:

34 MJ, 4 tile commercial quality ceramic burner (for 9kg LPG bottle l not included)
Manual integrated Piezo ignition, with tilt safety switch and flame failure device
Fully concealed gas pipes and bottle
In-built wheels for easy portability and storage
Components are sub-assembled for easy DIY installation
High/Low heating output
Protective grille and reflector included as standard, to guarantee safe operation
2 year residential and 1 year commercial warranty
Optional Cover Available (TGHCOVER) not included

MODEL	TILES	MJ	IGNITION	DIMENSIONS (mm)	WEIGHT (kgs)	HEATING AREA (m2)
TGH34PL	4	34	Manual, Piezo	650(w) x 670(D) x 2118(H)	31.5	16

Heatstrip Elegance Heater in White w/ Remote and App

$864.43

With superior technology and style, world-leading design and unique “off-white” colour, the new HEATSTRIP® Elegance with Remote will blend in with the white ceiling in your alfresco-area, with the easy control of heat settings.

Features:

Electric radiant outdoor heater 2 Models available THE2400RA (2400W) & THE3200RA (3200W)
Control the heater operation (WiFi & Bluetooth) via a smart phone APP (iPhone and Android). Also compatible with smart home voice-controls systems such as Google Hub & Amazon Alexa.
Slimline design and “off-white” colour
New compact and higher output design
Corrosion-resistant for most environments
Convenient DIY installation for the 2400W model. The 3200W model must be hardwired by a licensed electrician
Materials of Construction: High temperature off-white ceramic coated extruded alloy. IP55.
2 year residential & 1 year commerical warranty.

Order Code	Wattage	Current	Heating Area	Lead Length	Length	Width	Height	Weight	Plug
THE2400RA	2400w	10amps	4-5m²	1000mm	1306mm	170mm	42.7mm	7kg	YES
THE3200RA	3200w	13.3amps	5-6m²	1000mm	1710mm	170mm	42.7mm	9kg	NO

Heatstrip Elegance Heater in White w/ Remote

$786.45

Features:

Electric radiant outdoor heater
2 Models available THE2400R (2400W) & THE3200R (3200W)
New control panel with low, high temperature settings and timer
Slimline design and “off-white” colour
New compact and higher output design
Corrosion-resistant for most environments
Convenient DIY installation for the 2400W model. The 3200W model must be hardwired
Materials of Construction: High temperature off-white ceramic coated extruded alloy. IP55.
2 year residential and 1 year commercial warranty.

Order Code	Wattage	Current	Heating Area	Lead Length	Length	Width	Height	Weight	Plug
THE2400R	2400w	10amps	4-5m²	1000mm	1306mm	170mm	42.7mm	7kg	YES
THE3200R	3200w	13.3amps	5-6m²	1000mm	1710mm	170mm	42.7mm	9kg	NO

Heatstrip Max DC Outdoor Heater in 2400w or 3600w with Remote

$689.00

Designed to maximise heat output, with world class quality and aesthetics. With a stylish hexagonal grille and black finish, it is ideal for the really hard to heat application including high ceilings, exposed alfresco balconies, pergolas, verandahs, warehouses and restaurants.

Features:

Dual Carbon element technology and upgraded heat reflector design that delivers maximum, world class heating performance.
2 Models available THX2400DCR (2400W) & THX3600DCR (3600W)
The new remote control heater has 1-3 temperature settings and 1-24 hour timer control.
Anodised alloy components provide corrosion protection, even suitable for coastal locations
Easy installation with the brackets included. Suitable for ceiling or wall mounting. 3600W model must be hardwired.
Commercial grade quality and construction, 2 years full replacement warranty.

Specifications:

Wattage: 2400w, 3600w
Current: 10amps, 15amps
Lead Length: 1000mm
Plug: Yes, No
Heating Area: 7-12m², 11-18m²
Materials of Construction: Anodised alloy casing and end caps, chromed grille. IPX5

Dimensions:

Length: 979mm, 1190mm
Width: 170mm
Height: 80mm

Heatstrip Replacement Remote for Elegance THE-R Range

$51.96

The HEATSTRIP Elegance Remote range comes with a remote control as standard. This replacement remote is a direct replacement in case you have damaged or lost your original remote.

Features

Suitable for Elegance Remote range only
Direct remote replacement
Black colour

Heatstrip Electric Radiant Heater in Black and Silver with Remote

$463.40

Black front face and anodised alloy casing Electric Radiant Heater With Remote

HEATSTRIP® TG2200RB Electric heater is for protected undercover outdoor and indoor areas such as alfresco areas, verandas, patios, garages, bathrooms etc.

Features:

2200 Watts
Gentle heat output, slimline design.
LED control panel with easy On/Off functionality, 3 heat levels and adjustable 0-24 hour timer.
Suitable to heat a 3-4m² area, when ceiling mounted.
Anodised alloy construction Profiled all-black heater. No glow.
Direct overhead ceiling mounting is the preferred mounting method.
Supplied with 1.5m lead, plug and mounting brackets for DIY installation.
12 month warranty.

Specifications:

Colour: Silver back casing with black radiant panel.
Power: 2200w
Current: 9.2amps
Plug: Yes
Heating Area: 3-4m²
High temperature ceramic coated extruded alloy.
IPX4 Rating.

Dimensions:

Length: 1144mm
Width: 162mm
Height: 50mm
Weight: 4.7kg
Lead Length: 1500mm

Heatstrip Electric Radiant Heater in Off-White with Remote

$558.60

HEATSTRIP® TF2200RW Electric heater is for protected undercover outdoor and indoor areas such as alfresco areas, verandas, patios, garages, bathrooms etc.

Features:

2200 Watts
Gentle heat output, slimline design.
LED control panel with easy On/Off functionality, 3 heat levels and adjustable 0-24 hour timer.
Anodised alloy construction Profiled off-white heater. No glow.
Direct overhead ceiling mounting is the preferred mounting method.
12 month warranty.

Specifications:

Colour: Off-white
Power: 2200w
Current: 9.2amps
Plug: Yes
Heating Area: 3-4m²
Materials of Construction: Anodised alloy construction. Profiled off-white front panel.
IPX4

Dimensions:

Length: 1144mm
Width: 162mm
Height: 50mm
Weight: 4.7kg
Lead Length: 1500mm

Heatstrip TG2200RB Electric Heater Replacement Standard Bracket

$47.70

Replacement Standard Bracket for TG2200RB

Heatstrip (THY-W) intense Electric Heater 2200w White

$494.20

The new HEATSTRIP^® Intense wall/ceiling mounted electric infra-red heater is a modern and attractive outdoor heating solution. With a carbon filament element infra-red heating element this slimline heater provides high-performance instant heat. The high-temperature output of the HEATSTRIP^® Intense is perfect for exposed outdoor sites, high ceilings and hard to heat indoor and outdoor applications. With black and white models available, this heater can blend into a white ceiling, or be a feature to any outdoor area.

Featues:

Ideal for undercover protected and semi-exposed outdoor locations
2 Models available THY2200W (2200W) & THY3200W (3200W)
Easy DIY installation for 2200W unit, 3200W heater must be installed by a licensed electrician
Carbon filament infra-red heating element provides high performance instant heat
2-year residential and 1-year commercial warranty

Mounting:

The installation of HEATSTRIP^® Intense is simple and easy with the standard mounting brackets supplied. For other locations, there are a range of mounting options available – (refer to below diagrams). The HEATSTRIP^® Intense can be mounted directly to the ceiling; angled downwards on a wall; fitted flush with the ceiling; suspended on chains or poles; attached to beams/poles/umbrellas; mounted end-to-end, or 2 units together.

Minimum mounting height (including flush mount) 2.1m
Ideal mounting height (including flush mount) 2.2m – 2.5m
Maximum mounting height (including flush mount) 2.8m

Specifications:

Wattage: 2200w
Material: Alloy
Colour: White
Voltage: 240v, 50-60Hz
IP Rating: IPX5

Order Code	Wattage	Current (Amps)	Length	Width	Height	Weight	Lead Length	Plug	Heating Area
THY2200W	2200w	9.2	1068mm	120mm	90mm	6kg	1000mm	YES	5-9m²

Heatstrip Max DC + Remote Flush Mount Enclosure in Black

$311.52

Features:

The Flush Mount Enclosure is an ideal way to neatly install the HEATSTRIP® Max-DCR into a ceiling.
They are available for both HEATSTRIP® Max sizes and are supplied as a one-piece unit for mounting of heaters.
Flush mounting can be used with plaster or wood lined ceiling materials.
An ideal mounting height is 2.4m - 2.7m, with a maximum ceiling height of 3m in an outdoor environment.
Maximum mounting heights should be strictly followed, otherwise the performance of the units may be reduced.
The facia of the enclosure is manufactured from 316 Stainless Steel and powder coated black and the rear casing is black zinc coated steel.
Please refer to the Installation Manual for more detailed installation information.

Specifications:

Material: Steel
Colour: Black

Dimensions:

Length: 1146mm
Width: 290mm
Depth: 180mm
Cut-Out: 1088mm x 234mm

Order Code:

THXAC-034 - Flush Mount Enclosure for THX2400DCR (2400w)
THXAC-035 - Flush Mount Enclosure for THX3600DCR (3600w)

Heatstrip Max DCR Range Replacement Remote

$64.99

The HEATSTRIP Max DC Remote range comes with a remote control as standard. This replacement remote is a direct replacement in case you have damaged or lost your original remote.

Features

Suitable for Max DC Remote range only
Direct remote replacement

Heatstrip Nano Portable Electric Heater

$249.90

Model THN2000, 2000Watts The new entry level HEATSTRIP® Nano wall / ceiling mounted electric infrared heater is an ideal spot heating solution for many indoor and outdoor heating applications with the convenience of heat output and timer control, operation is so simple.

Features:

Easy DIY installation with wall/ceiling mount brackets included
Remote control operation, with 4 heat settings and 24 hour timer & LED display
Carbon filament infra-red heating element provides high performance instant heat
Suitable for spot heating in outdoor and indoor applications as protected undercover alfresco areas, garages, sheds, bathrooms, cafes , warehouses, showrooms and offices
18 month residential and 12 month commercial warranty

Specifications:

Power: 2000w
Current: 8.3amps
Plug: Yes
Heating area: 5-9m²
Materials of Construction: (Heater) Black anodised alloy casing and end caps, with a powder coated grill (Black) IPX5

Dimensions:

Length: 900mm
Width: 130mm
Height: 89.5mm
Lead Length: 2000mm
Weight: 3kg

Heatstrip Nano Portable Electric Heater Stand

$173.25

Optional stand for the Heatstrip Nano heater (heater not included).

Spare Remote For Heatstrip THH-AR Range

$51.98

Angled Wall Mount Bracket For Heatstrip THH and THE Series

$130.90

HEATSTRIP Wall Mounting Kit is an ideal way to install units into hard to mount applications where wall mounting is preferable to direct overhead mounting, applications include heating over tables, lounges, work stations etc. These kits are suitable for all HEATSTRIP Elegance & Classic models.

Specifications:

Material: Powder coated Mild Steel
Length: 550mm
Width: 165mm
Height: 250mm
Weight: 3.5kg

Flush Mount Enclosure Black For Heatstrip THH-AR Range

$336.00

The Flush Mount Enclosure is an ideal way to neatly install the HEATSTRIP® into a ceiling. They are available for all HEATSTRIP® Classic models, and are supplied as a one-piece unit suitable for mounting individual heaters. Flush mounting can be used with plaster or timber lined ceiling materials.

An ideal mounting height is 2.3m-2.5m, with a maximum ceiling height of 2.7m in an outdoor enclosed environment. Maximum mounting heights should be strictly followed, otherwise the performance of the units may be reduced.

Order Code	Suitable For Models	Hole Cut Out	Overall Dimensions	Weight
THHAC-013	THH2400AR	1420mm x 230mm	1470mm x 280mm x 125mm	8kg
THHAC-014	THH3200AR	1830mm x 230mm	1880mm x 280mm x 125mm	9kg

Heatstrip Nano Portable Electric Heater Spare Remote

$49.34

Spare remote for Nano Portable Electric Heater

Heatstrip (THH-AR) Classic with Remote Radiant Electric Heaters 2400w, 3200w Black

$665.00

With superior technology and style, world-leading design and “all-black” colour, the new HEATSTRIP® Classic with Remote will Make a statement in your alfresco-area, with the easy control of heat settings.

Features:

Electric radiant outdoor heater
2 Models available THH2400AR (2400W) & THH3200AR (3200W).
The new remote control heater has 1-3 temperature settings and 1-24 hour timer control.
Slimline design and “all black” colour
New compact and higher output design
Corrosion-resistant for most environments
Convenient DIY installation for the 2400W model. The 3200W model must be hardwired
Materials of Construction: High temperature ceramic coated extruded alloy.
IP55 Rated.
2-year residential and 1-year commercial warranty.

Mounting:

The installation of HEATSTRIP^® Classic is simple and easy with the standard mounting brackets supplied. For other locations, there are a range of mounting options available – (refer to diagrams). The HEATSTRIP^® Classic can be mounted directly to the ceiling; angled downwards on a wall; fitted flush with the ceiling; suspended on chains or poles; attached to beams/poles/umbrella’s; mounted end-to-end, or 2 units together.

Minimum mounting height (including flush mount) 2.1m
Ideal mounting height (including flush mount) 2.2m – 2.5m
Maximum mounting height (including flush mount) 2.7m

*Chain/wire not included

Model	Wattage	Current	Length	Width	Height	Weight	Lead Length	Plug	Heating Area
THH2400AR	2400w	10 amps	1371mm	165mm	48mm	7kg	1000mm	YES	4-5 m²
THH3200AR	3200w	13.5 amps	1780mm	165mm	48mm	9kg	1000mm	NO	5-6m²

Heatstrip Nano Portable Electric Heater with Stand

$473.54

The new HEATSTRIP Nano Portable Electric Heater is an ideal spot-heating solution for many indoor and outdoor heating applications with the convenience of heat output and timer control, operation is so simple. The stand pole is height adjustable (120 cm to 205 cm), and 360º rotatable. The weight of the stand base is 8 kg, which provides great stability while maintains the portability of the heater.

Features:

Stand is height adjustable and 360º rotatable
Easy DIY installation with stand and optional wall/ceiling mount brackets included for flexible placements
Plug in & play with power cable & plug supplied, no hardwiring needed
Remote control operation, with 4 heat settings and 24 hour timer & LED display
Carbon filament infrared heating element provides high performance instant heat
Suitable for spot heating in outdoor and indoor applications as protected undercover al fresco areas, garages, sheds, bathrooms, cafés, warehouses, showrooms and offices

Specifications:

Heater type: Electric radiant, infrared overheat heater with carbon filament element
Output: 800/1200/1600/2000 Watts
Current: 8.3 amp
Power: 230-240 Volts nominal at 50-60 Hertz, single phase
Heating area: 4-5 m² (outdoor enclosed), 8 m² (indoor protected)
Power plug: Yes
Installation: DIY installation
Protection rating: IP55 protection from water ingress from all directions
Materials of construction (heater): Anodised alloy casing with 304 stainless steel grille
Materials of construction (stand): Powder-coated mild steel
18-month residential or 12-month commercial warranty

Dimensions:

Width: 900mm
Depth: 450mm
Height (minimum): 1200mmm
Height (maximum): 2050mm
Weight: 13 kg

Heatstrip Universal Stand in Black

$251.99

All-black universal stand suitable for all spot heating applications, protected alfresco area, balcony, patio or verandah. Also suitable for indoor use such as warehouses, assembly line, showrooms etc.

Features:

Indoor/outdoor universal stand
Stylish, high quality all-black construction, portable stand
Components are sub-assembled for easy DIY installation
Materials of Construction: Powder Coated Mild Steel
1 Year residential and commercial warranty.

The HEATSTRIP Universal Stand (THSTAND) has been designed for 2400 Watt or below heaters. We recommend Heaters 1800W, 2200W & 2400 Watt as they are easy to install as they are 10amp or below. Our heater power cords come as a standard 1m and will need an extension cord to connect to power.

While we recommend smaller wattages as its easier to install our larger 3200 or 3600 Watt heaters* can be installed on the THSTAND. A licensed electrician must install your heaters as the larger models are 13.3-15 amps and must be hardwired.

*If you choose to install a larger heater, due to the weight of the heater, you must secure the stand via the base brackets to the floor by screwing it down. (Base fixing screws are not provided)

In most outdoor or difficult-to-heat indoor applications, there are 2 methods when looking at the size and quantity of heaters required.
Option 1 is to comfort heat the entire area based on the total dimensions of the space, regardless of whether the entire area is being fully occupied or not.
Option 2 is to spot heat the high use areas, such as over outdoor tables, BBQ’s, lounges, assembly lines or indoor work-stations. Often it is more practical and efficient to spot heat these areas.

Spot heating will help to reduce the initial capital cost, as well as the on-going running costs. Spot heating will allow the area to be “zoned”, meaning heating only the areas that are being used, such as tables in a restaurant or outdoor alfresco area.

Dimensions:

Height: 2050mm
Length: 450mm
Width: 450mm
Weight: 11.2kg

Replacement Standard Mounting THG-BA Brackets (2 in pack)

$45.83

Specifications:

Colour: Black
Material: Alloy
Weight: 0.2kg

Heatstrip (THG-BA) Enhance with Remote and App Control 3200w Black

$665.00

This sleek, slimline heater with a smooth German Schott glass front is the perfect all-black electric heating solution for instant performance. Easily control the heater with the included remote and app, with a timer rang-ing from 0-24 hours and 3 different heating levels. Whether you need localised or direct spot heating indoors or outdoors, this heater is sure to meet your needs.

Features:

Indoor/outdoor electric radiant heater.
Available - THG3200BA (3200 Watt)
Sleek, slimline appeal with a smooth German-made Schott glass front panel
Remote, app plus smart home connectivity. Compatible with Google and Amazon smart home platforms. Bluetooth & WIFI
Remote control provides 3 heat levels with adjustable timer options from 0-24 hours with the touch of a button.
3200w model must be hard-wired and installed by a licensed electrician.
Ideal mounting height 2.1-2.5m. Max mounting height 2.7m.

Specifications:

Colour: Black
Wattage: 3200w
Current: 13.5 Amps
Voltage: 240v, 50-60Hz
IP Rating: IPX5
Plug: No
Heating Area: 8-10m²
Material: (Face) German schott glass (Casing) High temperature black coated extruded alloy.

Dimension:

Length: 1020mm
Width: 187mm
Height: 76mm
Lead Length: 1000mm
Weight: 10kg

Heatstrip Replacement Remote for TT-MTM

$62.99

Heatstrip® Replacement Remote for TT-MTM heater controller

Features:

Provide ON/OFF control with 3 heat options and a timer setting
3 heat settings – High / Medium / Low

Heatstrip Replacement Remote for TT-MTR-PLUG

$42.08

Heatstrip® Replacement Remote for TT-MTR-PLUG

Remote control unit only to suit Heatstrip plug in timer
