The installation of HEATSTRIP® Intense is simple and easy with the standard mounting brackets supplied. For other locations, there are a range of mounting options available , (refer to below diagrams). The HEATSTRIP® Intense can be mounted directly to the ceiling; angled downwards on a wall; fitted flush with the ceiling; suspended on chains or poles; attached to beams/poles/umbrellas; mounted end-to-end, or 2 units together.
- Minimum mounting height (including flush mount) 2.1m

- Ideal mounting height (including flush mount) 2.2m , 2.5m

- Maximum mounting height (including flush mount) 2.8m

The mounting height of the electric heater can have a significant impact on performance. For mounting heights higher than the ideal range, we recommend the use of wires/chains or optional extension poles to reduce the height and ensure the heater is within the ideal range. Heater performance may be affected if outside this range.
Specifications:
- Wattage: 2200w

- Material: Alloy

- Colour: White

- Voltage: 240v, 50-60Hz

- IP Rating: IPX5

| THY2200W |
2200w |
9.2 |
1068mm |
120mm |
90mm |
6kg |
1000mm |
YES |
5-9m2 |
