Description: The EDM Series can be wall or ceiling mounted and is designed to exhaust stale and moist air from bathrooms, toilets, laundries etc. They are also suitable for ventilating all types of small or closed areas.
.
Features:
• Type - shaded-pole induction motor.
• Electricity supply - 220-240v, single-phase, 50Hz
• Bearings - sleeve
• Maximum ambient temperature - 40°C
Internal Thermal Protection:
• Model 100 - impedance
• Model 200 & 300 - fuse
Special Features: •
‘S’ Range - Standard unit (without shutters); all sizes.
•
‘C’ Range - Standard unit with shutters; all sizes.
•
‘CT’ Range - Unit complete with fixed run-on timer and shutters; sizes 100 and 200 only.
•
‘CR’ Range - Unit complete with adjustable run-on timer and shutters; size 300 only.
•
Low Voltage 12V - Unit suitable for wet areas (IPX7), requires low voltage transformer; size 100 only.
• All ranges can be used to exhaust along a short duct, air flows in this situation are reduced.
• All models except the EDM-100S feature a pilot lamp
| Description |
Diameter |
Speed |
kW |
Amps |
AVG db(A)
@3m |
Max Pressure |
Max Volume |
| 240v 13w 2P 36DBA@3M 98mm Ceiling/Wall with Shutter |
ø100mm |
41 |
0.013 |
0.1 |
36 |
19 |
108m³/h
|
| 240v 13w 2P 36DBA@3M 98mm Ceiling/Wall with Timer & Shutter |
ø100mm |
41 |
0.013 |
0.1 |
36 |
19 |
108m³/h
|
| 240v 13w 2P 36DBA@3M 98mm Ceiling/Wall Standard |
ø100mm |
41 |
0.013 |
0.1 |
36 |
19 |
108m³/h
|
| 12v AC 13w 36DBA@3M 98mm Ceiling/Wall Standard |
ø100mm |
41 |
0.013 |
0.1 |
36 |
19 |
108m³/h
|
